Product Details:
|
| Color: | White | Gas Type: | NG/LPG |
|---|---|---|---|
| Installation: | Wall Mounted | Style Of Frequency Conversion: | Stepless |
| Display: | LED Displayer Optional | Housing Material: | Stainless Steel |
| Main Component: | Top Quality | Gas Pressure(pa): | 2000/2800 |
| Power (w): | 40/32/28/26KW | ENERGY EFFICIENCY: | First Level |
| Thermal Efficiency(%): | ≥90 | Pretection Mearure Kind: | 21 Kinds Of Security Protection Measure |
| Product Name: | Wall Mount Gas Boiler | CONTROL SYSTEM: | Intelligent Style |
| High Light: | White Shell Wall Hung Gas Boiler,Wall Hung Gas Boiler Stepless,Stepless Frequency Conversion Hot Water Furnace |
||
Gas Wall Hanging Hot Water Furnace Top Quality White Shell Stepless Frequency Conversion
Function of temperature sensor: The temperature sensor of gas wall hanging furnace is
divided into heating and hot water temperature sensor, it senses the running
temperature of hot water and heating, and can obtain very accurate temperature, so
that the application of wall hanging furnace is more convenient and accurate.
Product Main Technical Parameter Table
| the rated powder input(KW) | 20 | 24 | 32 | 42 |
| the rated powder output(KW) | 21.6 | 25.9 | 34.5 | 45.3 |
| the thermal efficiency(%) | ≥108 | ≥108 | ≥108 | ≥108 |
| rated voltage frequency(V/Hz/W) | 220/230/50 | 220/230/50 | 220/230/50 | 220/230/50 |
| the gas pressure(Pa) | natural:2000 | the gas pressure:2800 | ||
| living hot water temperature adjusting range(℃) | 30-80 | 30-80 | 30-80 | 30-80 |
| heating watertemperature adjusting range(℃) | 30-80 | 30-80 | 30-80 | 30-80 |
| domestic hot water production(kg/min ) | 8 | 9.4 | 13.6 | 17.5 |
| living hot water apply pressure(mpa) | 0.5-6 | 0.5-6 | 0.5-6 | 0.5-6 |
| heating system apply pressure(mpa) | 0.5-2 | 0.5-2 | 0.5-2 | 0.5-2 |
| the hightest pressure heating system(mpa) | 3 | 3 | 3 | 3 |
| height,width,thickness(mm) | 740*410*315 | 740*410*315 | 740*410*315 | 740*410*315 |
| weight(kg) | 40 | 40 | 40 | 40 |
| pipe connectors(G) | heating water supply:3/4 | heating water supply:3/4 | heating water supply:3/4 | heating water supply:3/4 |
| diameter of smoke pipe(mm) | 60/100 | 60/100 | 60/100 | 60/100 |
Qingdao Hiounce HVAC Equipment Co., Ltd. is located in the beautiful coast al city of Qingdao, is a gas heating furnace,condensing gas boiler, gas module furnace as the leading, set design, research and development, production, sales in one of the high-tech enterprises.
The company has more than 100 employees, the company covers an area of 13600 square meters, plant area of 7500 square meters, all kinds of production and processing equipment more than 100 sets. The company has an annual output of 120,0 00 sets of wall mounted furnace and modern production line and equipped with advanced testing equipment. According to the high standard of the industry, the company built the research and development laboratory, the life laboratory, the incoming material laboratory and the finished product laboratory.
Q:Are you trading company or manufacturer ?
A:We are factory,located at Qingdao City, China. Welcome your visitanytime!
Q:How can I get the price?
A:We usually quote within 24 hours after we get your inquiry(Exceptweekend and holidays).lf the quantity is not too much, we can offerfor free but delivery cost should be collected. Different products have different MOO, we can discuss step by step.
O:What is the lead time?
A:Usuallv,for small order, our lead time is 15-30davs.If bulk order isover 10000pcs,lead time needs to be discussed step by step.We havestock for most ofour models.
Q:What is your payment terms?
A:We accept T/T and L/C. Others we can dicsuss together.lf you canpay RMB, it will be better.
Q:Do you have a guarantee of your product quality?
A:Now our products are produced in strict quality control system anddefective rate is un-der0.01%. For the defective products, we cansend new ones to replace along with your new order.
Q:What is the shipping method?
A: It could be shipped by sea,by air or by express(EMS,UPSDHL.TNT.FEDEX and ect). Please confirm with us before placing orders.
Q:What is your major product?
A: Our major product is Wall hung gas boiler,Condensing gas heatingboiler.Gas Water Heater, Electric Water Heater, Gas Hob, Range Hood, Gas Oven, and other kitchen appliances.
